Hot selling MD-6H 400*300*500mm fdm Printer 3 D Drucker industrial grade 3D for prototyping model making | Компьютеры и офис

---

Product Description



MINGDA MD-6H 400*300*500mm Industrial 3D printing machine



Please feel free to contact with MINGDA for promotion price.  No screws and sharp corner, safe usage Fully enclosed metal frame design Steady 3D printer without shake



TECHNICAL SPECIFICATIONS

1)MD-6H X,Y,Z axis adopt full linear guide rails , make our 3D PRINTER machine more stable than screw structure.
2)3D printer Printing speed 0-200mm adjustable.
3)It has 5.0 inch colorful touch LCD screen, very easy to operate.
4)10mm thickness aluminum heated bed, it max temperature can heat 110 degree. Will be easy to print strong filaments like ABS and Nylon.
5)0.4mm nozzle (easily changeable) for 1.75 mm filament. Self-patent nozzle max temperature 275 degree, no blocking and drawing.
6)Our printing head support almost any existing filament including : PLA, ABS, PLA composites (Carbon fiber, Wood, Copper, Brass, Magnetic ), PHA, PVA , Hips, Nylon, TPE & TPU (FleX) , PETG...
7) All metal stainless steel fully enclosed structure,can keep constant temperature, which is better for more filaments like ABS printing.
8) 0.05mm layer thickness, matching with it's full enclosed structure and stable full linear guide rails, to promise best stability and precision.
9) UPS (Uninterruptible Power System), when power off, our machine will stop working and keep memory for 24 hours. Which is very important for the big size model..
10) Filament sensor, 3d printer machine will stop working if no 3D printer filament, and will work if reinsert new materials.
11) Auto Power-off, the machine can be auto power-off after finishing printing model. So, if you want to go out or do anything which take longer time, you don't worry the question of power-off.

PRINTING
Build Volume	400*300*500 mm
Weight	N.W.61KG/ G.W. 98KG
Layer Resolution	0.05 mm
Filament Diameter	1.75 mm
Filament Compatibility	PLA, ABS, Carbon Fiber, Wood, Nylon, PC, PTEG, HIPS, PP, Flexible, TPU, PVA etc.
Nozzle Diameter	0.4mm ( 0.6, 0.8, 1.0mm)
TEMPERATURE
Max. Nozzle Temp.	275°C
Max. Bed Temp.	110°C
SPEED
Best Printing Speed	50 mm/s
Max Printing Speed	200 mm/s
MECHANICAL
Platform	10mm thickness aluminum hot bed
Levelling	Factory Leveled, Adjust Manually
X Y Position Precision	0.006 mm
Z Position Precision	0.0015 mm
ELECTRICAL
Power Requirements	95-265V, 50-60HZ
Max. Power	700W
Connectivity	USB,SD card
SOFTWARE
Software Bundle	Muti-Language
Support Software	Simplify3d, Cura, Slic3r, etc.
Supported File Types	STL,g-code
Operating Systems	Windows (7,8,10) Mac OS X
SPECIAL FUNCTION
Uninterruptible Power System	Save data when power is off
Filament Detection	Pause printing when filament run out
Automatic Shutdown	Turn off the power automatically when printing is complete

Details Images Application Industrial grade 3D printers are successfully used in many different industries, such as auto parts, construction, aerospace, lighting, furniture, machinery and other industries. Today we share some pictures and successful cases of the large models, I hope you like it. More different parts waiting for you to print...... Now we accept free sample printing, contact with us if you want to print sample to check performance. Click and send inquiry to us with more details Clients' Feedback We mainly focus on industrial grade 3d printer over 10years. This year, we have upgraded all our industrial grade 3d printers, now we have MD-4H, MD-6H, MD-666 PRO, and MD-1000 PRO in stock. For MD-6H, we have received lots of good feedback from differents . Here is one of the videos that client prined carbon fiber filament by MD-6H, and some other feedbacks.   Packing & Shipping

How to pack MINGDA 3D printer?

1. One set 3D printer machine
2. One roll filament , one masking tape
3. Power plug and USB cable
4. SD card with manual, software and some model samples
5. One maintenance kit (spare nozzles, tubes, Tweezers, Tape, Knife, pliers, screwdrivers etc)
6. Standard international strong wooden package , suitable to long-distance transportation

How will you shipping MINGDA 3D printer to my destination?

Our 3D printer shipped by different transportation,you can choose the most convenient method. Generally, MINGDA always ship 3D printers by air and sea. In the mean time, MINGDA has cooperated with international express such as DHL, UPS, TNT to enable our customers get the 3D printer rapidly.

Company Profile Shenzhen Mingda Technology Co., Ltd
has more than 11 years of manufacturing and design experience for 3D printers. We specialize in researching and production of 3D printers and 3D filaments. We have professional R&D team, domestic advanced production equipment and precision instruments.
Quality Guarantee is always our aim. We have proven to be a dependable, trustworthy, engaged and efficient company that always adheres to increase customers' satisfaction.All our products have pass CE,FCC,ROHS, ISO9001 certificates.

We focus on professional industrial 3d printer MD 4H / 6H/ 666/1000 , printing size from 300*200*200mm to 1000*1000*1000mm. and new resin 3d printer and newest DIY 3d printer, which will extend your profile and profit, So I think our possibility of cooperation definitely exist.
Let us work together to open up new prospects for win-win cooperation! Exhibitions FAQ

FAQ (Frequently Asked Question) of MINGDA Professional FDM 3D Printer

1. Q: What type of software can I use in MINGDA 3D printers?
A: 3D printer is only as good as the design it's given to print. And to design and format prints, you'll need the right software
-- specifically design and slicing software. There are options to meet every ability level and budget, but all printers are
compatible and some even require the use of proprietary software. MINGDA printers are designed for compatibility with many open-source and commercially available software. For more help in choosing the software that's right for you, see our Software Guide here.

2. Q: What type of filament is compatible with MINGDA 3D printers?
A: Some printers on the market are only compatible with proprietary filament, which is often more expensive and limiting in terms of types and colors of materials available. Knowing the cost and availability of these items up front will save you down the road.
At MINGDA, we've designed our machines to work with a broad range of commercially available filaments, including PLA, ABS, TPU, HIPS, Nylon, Wood, Carbon Fiber, Copper etc.

3. Q: Do MINGDA 3D printers have a heated print bed?
A: Yes, 10mm thickness aluminum plate. One of the most critical aspects required for a great print, is the adhesion of the first layer to the printing surface. Some materials will not adhere to the surface unless it is heated to a specific temperature. MINGDA 3D printers come standard with a heated build platform. It heats evenly across the entire build plate from corner to corner, and heats up to 110 °C and higher to ensure you get excellent adhesion.

4. Q: How often will MINGDA 3D printers need to be leveled?
A: Ensuring your print bed is leveled before printing is a critical step in achieving great prints. The more your printer jostles out of alignment, the more often you need to stop to re-level your printer. We've designed our MINGDA 3D printers with true level calibration - Four Big Screws to ensure that it's easy for you to properly level and it stays level. No more fussing! According to the customer's feedbacks, it's almost no need to adjust the heated bed if using our industrial 3D printer.

5. Q: What is the MINGDA 3D printers constructed out of -- steel or acrylic?
A: Great prints require stability and rigidity from the machine, and that starts with the printer's frame. Frames constructed out of materials such as acrylic or light gate steel can warp or fall out of alignment, which will diminish the quality of your prints in due time. MINGDA industrial 3D printers are built out of strong stainless steel in fully enclosed structure. You can rest assured, it will stay square year-after-year.
  If you still have any question or want to know more details, please contact us online or send an inquiry to us. Maybe you like   Welcome to send us inquiry to get newest Promotional Price and more informotions.
